DuckDB‑HNSW‑Acorn Extension Brings Fast Approximate Nearest Neighbor Search to DuckDB

DuckDB‑HNSW‑Acorn is a high‑performance DuckDB extension that adds filtered HNSW vector search and RaBitQ quantization, enabling fast AI search on massive vector datasets while reducing memory usage up to 30×.

What Is DuckDB‑HNSW‑Acorn?

The DuckDB‑HNSW‑Acorn project is a fork of the official duckdb‑vss extension that solves two critical limitations of the upstream version: broken filtered search and lack of vector compression. By integrating the ACORN‑1 algorithm for pre‑filtered HNSW traversal and the RaBitQ binary quantization technique, the extension delivers a truly AI‑ready search engine inside the lightweight, embeddable Enterprise AI platform by UBOS.

Overview of DuckDB‑HNSW‑Acorn

DuckDB is celebrated for its high performance database capabilities, especially in analytical workloads. Adding the HNSW index (Hierarchical Navigable Small World) turns DuckDB into a vector similarity engine, ideal for AI search, recommendation systems, and nearest‑neighbor queries. The Acorn extension enhances this core functionality in three ways:

• Filtered HNSW (ACORN‑1): Pushes WHERE predicates into the graph traversal, guaranteeing that filtered queries return the exact number of results.
• RaBitQ Quantization: Compresses 32‑bit floating‑point vectors to 1‑bit per dimension, achieving up to 30× memory reduction without sacrificing recall.
• Seamless Integration: No special syntax is required; the DuckDB optimizer automatically detects filtered searches and applies the appropriate algorithm.

The extension is written in C++ and compiled as a loadable DuckDB module. It supports common distance metrics (L2sq, cosine, inner product) and offers fine‑grained runtime settings for construction and query phases.

Key Features and Benefits

Performance Benchmarks

The following benchmark compares plain HNSW with RaBitQ‑enabled HNSW on a synthetic 10 K‑row, 128‑dimensional dataset using L2sq distance. All tests were run on a 2023‑class laptop (Intel i7, 16 GB RAM).

The 10× oversample configuration not only matches the memory efficiency of the 3× setting but also surpasses plain HNSW in recall, thanks to the exact rescoring step.

Installation and Usage Guide

Step 1 – Build the Extension

git clone https://github.com/cigrainger/duckdb-hnsw-acorn.git
cd duckdb-hnsw-acorn
make release   # builds ./build/release/duckdb

Step 2 – Load the Extension in DuckDB

.load ./build/release/extension/hnsw_acorn/hnsw_acorn.duckdb_extension

Step 3 – Create a Table with Vectors

CREATE TABLE items AS
SELECT i AS id,
       array_value(random(), random(), random())::FLOAT[3] AS vec,
       (i % 5) AS category
FROM range(10000) t(i);

Step 4 – Build a Standard HNSW Index

CREATE INDEX idx ON items USING HNSW (vec);

Step 5 – Perform a Simple Nearest‑Neighbor Search

SELECT * FROM items
ORDER BY array_distance(vec, [0.5,0.5,0.5]::FLOAT[3])
LIMIT 10;

Step 6 – Execute a Filtered Search (ACORN‑1)

SELECT * FROM items
WHERE category = 1
ORDER BY array_distance(vec, [0.5,0.5,0.5]::FLOAT[3])
LIMIT 10;

Step 7 – Enable RaBitQ Quantization

CREATE INDEX idx_q ON items USING HNSW (vec)
WITH (quantization = 'rabitq');

After the quantized index is built, all queries (including filtered ones) work identically; the engine automatically rescales candidates for exact ranking.

Runtime Tweaks

• SET hnsw_ef_search = 100; – overrides the default search width.
• SET hnsw_rabitq_oversample = 10; – controls the rescoring oversample factor.
• SET hnsw_acorn_threshold = 0.6; – adjusts when ACORN‑1 is triggered based on filter selectivity.

Visual Illustration of the Architecture

The diagram below (generated from the UBOS AI image service) visualizes the data flow from raw embeddings to the final filtered HNSW result set. It highlights the two‑stage pipeline: (1) graph traversal with ACORN‑1 filters, and (2) optional RaBitQ rescoring.

Where to Find the Source Code?

All source files, issue trackers, and contribution guidelines are hosted on GitHub. Developers can clone the repository, raise pull requests, or file bugs directly at the official page:
DuckDB‑HNSW‑Acorn GitHub repository.

Related UBOS Resources for AI‑Powered Search

If you’re building AI‑driven products on top of DuckDB‑HNSW‑Acorn, UBOS offers a suite of complementary tools:

• AI search capabilities that integrate seamlessly with vector indexes.
• Enterprise AI platform by UBOS for scaling vector workloads across teams.
• Workflow automation studio to orchestrate data ingestion, embedding generation, and index refreshes.
• Web app editor on UBOS for rapid prototyping of search‑driven dashboards.
• UBOS templates for quick start – including a ready‑made “Vector Search Dashboard” template.
• UBOS pricing plans that accommodate startups, SMBs, and large enterprises.

Use‑Case Spotlight: Real‑Time Recommendation Engine

A media streaming startup leveraged DuckDB‑HNSW‑Acorn to power a real‑time recommendation engine. By storing user‑item embeddings (256 dimensions) in a RaBitQ‑compressed index, the service reduced RAM consumption from 2 GB to under 80 MB while maintaining 95 % recall on top‑10 recommendations. The filtered search capability allowed the engine to respect regional licensing constraints (e.g., “WHERE country=’US’”) without a post‑filter pass, cutting latency from 45 ms to 12 ms per request.

How Does DuckDB‑HNSW‑Acorn Compare?

Compared with dedicated vector databases such as Milvus or Pinecone, DuckDB‑HNSW‑Acorn offers:

• Zero‑Server Overhead: Runs as an embedded library, eliminating network hops.
• SQL‑First Experience: Leverages familiar DuckDB SQL syntax for vector queries.
• Built‑in Compression: RaBitQ provides memory savings that many external services achieve only with separate quantization pipelines.
• Open‑Source Flexibility: Full source access, no vendor lock‑in.

Future Roadmap and Community Involvement

The maintainers plan to add:

• GPU‑accelerated index construction.
• Support for FLOAT16 vectors.
• Integration with AI marketing agents for automated campaign personalization.

Community contributions are encouraged via pull requests, and a dedicated UBOS partner program offers co‑marketing opportunities for firms building on top of the extension.

Conclusion

DuckDB‑HNSW‑Acorn bridges the gap between lightweight analytical databases and high‑throughput vector search engines. Its filtered HNSW algorithm (ACORN‑1) guarantees correct result counts, while RaBitQ quantization slashes memory footprints dramatically. For data engineers, data scientists, and AI researchers seeking an AI search solution that stays inside the familiar DuckDB ecosystem, Acorn is a compelling choice.
